| Chamber of highly polished S.S. | Capacity |
| 555 (W)x 910 (H)x 605 (D)mm | 308 ltrs. |
Single Chamber Seed Germinator offered are constructed using thick mild steel sheet that comes in powder coated finish. Further, for durable finish quality, the inner chambers are made using heavy gauge stainless steel of SS-304 grade. Further, these also feature PUF insulated gap between walls as well as comes with provision of two doors. Out of these, inner door is constructed using thick plexiglass that allows easy viewing of samples without disturbing chamber temperature.
Features :
- Outer door made in mild steel sheet and comes with lock and key arrangement
- Can be provided with customized shelving options to suit individual requirements
- Provided with air circulation fans that offers uniform maintenance of temperature throughout chamber
- Temperature controlled through electronic digital temperature indicator cum controller (with variation of +-1 oc)
- Each chamber features stainless steel water reservoir at bottom
- Provides for humidity control from 90 to 95% (+-3 %)
- Of forced convection type
- Featuring use of hermetically sealed compressor
- Handles temperature variations from 5oc to 60oc�1oc
- Comes with mild steel sheet powder coated finish from outside
- Comes with stainless steel finish from inside
- Comes with thermostat control for desired process safety
- Features puf insulation support
- Comes with exterior illumination option through fluorescent tubes
- Microprocessor based temperature-humidity controller provision
| BRAND | MODEL NO |
| LAATU | PRYG-001 |
Specifications :
| Type | Forced Convection Type |
| Compressor | Hermetically Sealed Compressor |
| Temperature Range | 5oc To 60oc�1oc |
| MOC Outer | Mild Steel Sheet Powder Coated |
| MOC Inner | Stainless Steel |
| Safety Device | Thermostat |
| Insulation | GLASS WOOL |
| Illumination | Exterior Illumination by Fluorescent Tubes |
| Humidity | By Steam Process |
| Controller | Microprocessor Based Temperature-Humidity Controller |
| Programmable Timer Illumination | Exterior Illumination With 5 Levels Light Control (0%, 25%, 50%, 75% And 100%) |
| Size Inner (WxDxH) | 555mm x 605mm x 910mm |
| Capacity | 308 Ltrs |
| No. Of Shelves | 14 |
| Temperature | Ambient +5oc – 60oc In One Chamber 5oc – 60oc In One Chamber Or 5oc – 60oc ±1oc In Both Chamber |
| Electric Supply | 220/230V AC, 50/60Hz |
Applications :
- Biological Studies
- Forestry Research work
- Other similar applications
