CONSTRUCTION:
The unit is specially desined to meet the requirement of high Temperature 1200°C, the casting is made of M.S. reinforced with iron angles duly painted. Chamber made of ceramic Zirconium Board and elements are placed Horizontally in the chamber. Heating is done by imported Silicon Carbide Rods duly controlled by accurate step down Trasformers (Air Cooled), it saves energy upto 30% with easily replaceable Carbide Rods.These furnace have outstanding Temperature reliability and has large surface radiation ratio to inhance thermal efficiency andpower consumption. Control panel is fitted with Digital Temperature Indicator cum Controller upto 1100°C Control Panel is provided separately havimg Ammeter Volts Meter and Digital controller etc. Maximum Furance Temperature upto 1400°C working Temperature upto 900°C operatable in 220 Volts Single Phase AC supply.
Technical Specifications :
Heaters/Elements: Made of A-1 kanthal wire (14 gauge) for primary chamber & (17 gauge) for secondary chamber.
Insulation: Strong insulation is done with combination of insulating bricks & silicon fiber insulating blanket to avoid any heat loss.
Front Loading Type: It is portable in nature, which can easily placed in a small space in a corner of building.
Consisting of Dual Chamber: Works on thermal destruction using controlled combustion chamber; combustion is controlled and provides enough heat to destroy the waste into disposable state.
Door: Fitted with hinges & handle for proper sealing to avoid heat loss.
Temperature: Temperature of Primary/Burning chamber up to 850 deg. C and for secondary chamber 1000 deg. C.
Portable: Whole unit is mounted on sturdy wheels
CONTROL PANEL
Control Panel consists of 2 nos of Micro Processor Controlled Electronic Digital Temperature Controller cum Indicators, Main Line Indicator: “Red color” neon light will glow ‘ON’ shows that the current is coming to the oven. Load Indicator: “Green color” neon light Glows when supply to heaters are ‘ON’. Rotary Switches: To start the machine. M.C.B for safety.
MUFFLE FURNACE SPECIFICATION:
| Max temperature | 1200°C | ||
| Continuous operating temp. | 1000°C | ||
| Heating element | Kanthal – A1 | ||
| Furnace Thermocouple | K Type | ||
| Chamber MOC | Ceramic fiberboard | ||
| Exterior MOC | MS/SS | ||
| Insulation | 1400 ZTL board | ||
| Temperature controller | PID controlled with SILICON Controlled Rectifier | ||
| Power supply | 220 Volts 50Hz | ||
| Accessories | Asbestos Gloves, SS tong |
MUFFLE FURNACE MODELS WITH SIZE & VOLUME FOR TEMPERATURE RANGE (900 °C TO 1200 °C)
BRAND-LAATU
| Model | Chamber Size (inch) | Chamber Dimension (mm) | Volume (Liters) |
| PRYG-002 | 4 x 4 x 9 | 100 x 100 x 225 | 2 liters |
| PRYG-002A | 5 x 5 x 10 | 125 x 125 x 250 | 4 liters |
| PRYG-002B | 5 x 5 x 12 | 125 x 125 x 300 | 5 liters |
| PRYG-002C | 6 x 6 x 12 | 150 x 150 x 300 | 7 liters |
| PRYG-002D | 8 x 8 x 12 | 200 x 200 x 300 | 12 liters |
| PRYG-002E | 8 x 8 x 18 | 200 x 200 x 457 | 19 liters |
| PRYG-002F | 12 x 12 x 12 | 300 x 300 x 300 | 28 liters |
| PRYG-002G | 12 x 12 x 18 | 300 x 300 x 457 | 42 liters |
| PRYG-002H | 12 x 12 x 24 | 300 x 300 x 609 | 56 liters |
