MELTING POINT APPARATUS MICROPROCESSOR CONTROLLED
| Temp. Range | Ambient to 300ºC |
| Display | LCD, 16X2 lines alphanumeric display |
| Resolution | 0. 1ºC |
| Temp. Sensor | Grade “A” PT-100, Platinum Sensor |
| Sample Capacity | 3 Samples and one 8mm provision for Test Tube, for the determination of Boiling Point of Any Liquid. |
| Application Area | Silicon Oil Bath ( Made of High Temp. Toughened Glass) |
| Application | Suitable for Boiling & Melting Point |
| Melting View | Magnifying display of melting operation with the help of adjustable magnifying glass, Melting point reading hold on by activating the “HOLD” key & reading is protected from power failure till “RESET” is not activated. |
| Heating Control | Microprocessor controlled closed loop PID |
| Ramp Rates | 2ºC to 10ºC/minute (Selectable Auto-Low-High), |
| Serial Interface | RS-232C to PC |
| Memory | 100 Samples with Location |
| Power Supply | 230 V ± 10% AC, 50 Hz. |
| Automatic Ramp Rate Proceeding, Auto Gradient Rate of Heating Control. The unit consists of in built magnetic stirrer, glare free background illuminator and cylindrical silicon oil bath. The silicon oil bath consists of a plain cylindrical container of corning glass having capacity of about 200 ml. It is furnished with a Teflon cover fitted with special type of oil immersion heater, having three small holes for holding the capillaries, two 6.6mm hole for thermometer (for calibration if required ) and Temp. Sensor, another 8mm hole for Test tube, for the determination of boiling point of any liquid . A variable speed stirrer is fitted in it. The apparatus can be used for determination of boiling points, Temp. effect on viscosity /flow points and molecular weights by Rast’s method with suitable accessories.
Suitable for Dark Colored / all kind or any colored Samples, |
