Description

Performance Parameters

Purpose It a high-intensity light source that can be focused to shine a thin sheet of light into the eye
Microscope type Galilean with converging binocular tubes
Magnification selection Five step by drum rotation
Eye piece 12.5 X
Magnification ratio 6x, 10x, 16x, 25x, 40x
Slit width and length adjustablity Continuous type
Types of Filter Cobalt Blue, UV protection,Green and Heat Absorbing
Illumination lamp LED lamp
Table base movement Longitudinal, lateral and vertical movement
Backround illumination should be through in built cold light Yes
Fixation light source supplied Yes
Suitable UPS supplied with slit lamp Yes
UPS backup time in minute 30 min
Applanation tonometer with prism supplied Yes
Motorised table shall be supplied for raising and lowering slit lamp Yes
Source of power supply Single phase 230 V, 50 Hz
Power cable compactable with Indian plug Yes
Operating temperature and humidity 10 – 40 deg C and relative humidity of 15-90%
Spares bulbs provided 2
Spares Prism for Appalanation Tonomerter 1
Warranty (Option of comprehensive warranty is available through bidding only, which if opted will supersede normal warranty in the catalogue) 3
Product instruction manual shall be supplied Yes

Dimensional Parameters

Pupillary distance (PD) range in mm 55 to 75
Diopter adjustment range in dipoter -6D to +6D
Slit Angle in degree 0 to 180
Working distance range in mm 75 to 100
Chin rest vertical movement in mm Upto 55 mm
Size of Slit lamp (Lx W x H) in mm x mm x mm 355X300X705
Weight of Slit lamp in Kg 12.5
