Description

Product Details

Product Specification

Voltage 230V
Brand LAATU
Material Stainless steel
Model Name/Number 403/406
Temperature Range Ambient + 5 DegreeC to 99.9 DegreeC
Inner Chamber Mirror Polished S.S. 316 Material
Temp. Resolution 0.1 DegreeC
Display Type LED Digital Display
Insulation Glass Wool Insulatio.
I Deal In New Only
Volume Liter 7 Liters
Accuracy 0.5 DegreeC or better
Exterior body Matt finished S.S. 304 Material
Temp Uniformity +- 0.2 DegreeC at 37 DegreeC
Overall size 40 cm L x 15 cm W x 20 cm H (L x W x H)
Working size 30 cm L x 15 cm W x 15 cm D
Propeller S.S. 304 Material

Product Description

Other Details:



  • Used to maintain in water the Marshal specimens to be tested at 600 10 (Asphalt specimens) or 37.80 (Tar Specimens) as prescribed by the specifications.
  • The Same Water bath can also be used for Penetration test, Stripping test or even soundness test of cement with the use of additional accessories. Available in different sizes and temperature control system.


Specifications:



  • Temperature range from ambient to 100oC and temperature controlled by digital temp. Indicator cum controller with an accuracy of + 0.5oC.
  • A high speed stirrer with a motor of 1/20 HP is fitted to the unit for continuous stirring and this can maintain a uniform heating throughout the chamber.
  • The heating mechanism comprises of set of heaters pertaining to fast heating to operate 230 volts AC only.

Constant Temperature waterbath Digital Model Selection Guide

Chamber size (W x D x H)   Chamber capacity (Liters) Digital Model Numbers ( PRYG-051) Digital GMP Model Numbers ( PRYG-051DG)
30 x 15 x 15 cm 7 PRYG-051 PRYG-051DG1
35 x 15 x 15 cm 8 PRYG-051A PRYG-051DG2
25 x 20 x 20 cm 10 PRYG-051B PRYG-051DG3
30 x 25 x 20 cm 15 PRYG-051C PRYG-051DG4
25 X 25 X 25 cm 16 PRYG-051D PRYG-051DG5
35 x 30 x 17.5 cm 18 PRYG-051E PRYG-051DG6
45 x 30 x 17.5 cm 24 PRYG-051F PRYG-051DG7
45 X 30 X 25 cm 34 PRYG-051E PRYG-051DG8
45 x 35 x 30 cm 47 PRYG-051F PRYG-051DG9
50 x 35 x 30 cm 52 PRYG-051G PRYG-051DG10
50 x 60 x 35 cm 105 PRYG-051H PRYG-051DG11
    • Constant Temperature water bath Themostatic  Model Selection Guide
Chamber size (W x D x H)   Chamber capacity (Liters) Digital Model Numbers ( PRYG-051) Digital GMP Model Numbers ( PRYG-051)
30 x 15 x 15 cm 7  PRYG-051TH1 PRYG-051THA
35 x 15 x 15 cm 8 PRYG-051TH2 PRYG-051THB
25 x 20 x 20 cm 10 PRYG-051TH3 PRYG-051THC
30 x 25 x 20 cm 15 PRYG-051TH4 PRYG-051THD
25 X 25 X 25 cm 16 PRYG-051TH5 PRYG-051THE
35 x 30 x 17.5 cm 18 PRYG-051TH6 PRYG-051THF
45 x 30 x 17.5 cm 24 PRYG-051TH7 PRYG-051THG
45 X 30 X 25 cm 34 PRYG-051TH8 PRYG-051THH
45 x 35 x 30 cm 47 PRYG-051TH9 PRYG-051THI
50 x 35 x 30 cm 52 PRYG-051TH10 PRYG-051THJ
50 x 60 x 35 cm 105 PRYG-051TH11 PRYG-051THK
    Note – Price will be change as per specification
