VISCOSITY BATH

Description

• Kinematic viscosity is of primary importance in the design and selection of a wide range of petroleum products. Calibrated capillary viscometers are used to measure flow under geavity or vacuum at precisely controlled temperatures.
• Rectangular model having double walled construction with toughened glass observation window (254 W x 225 H mm).
• Illumination from rear side provided.
• Oil immersion heater.
• Bath opening 254 x 200 mm with cover having 6 openings of 50 mm in diameter to hold 6 viscometers with six bakelite holders.
• Liquid capacity 22 Litres.
• Microprocessor based PID temperature controller with PT-100 & digital read out, resolution, temperature accuracy of 0.1°C & -0.02°C.
• Efficient stirring system
• Temperature : 40°C & 100°C.
• Power supply : 230 V, 1 Phase, 50 Hz.
