| Catalog No. | PRYG-310( Economical) | PRYG-311 | PRYG-312 | PRYG-314 | ||
| Display | 4 Digit LED | 4 Digit LED | 4 Digit LED | Dual DisplayLED + LCD | ||
| pH | Range | 0 – 14 pH | 0 – 14 pH | Specification same as per NU-311+
Manual & ATC (Automatic Temp. Compensation) supplied with Temp. Sensor Resolution : 0.1ºC |
Specification same as per NU-312+
LED & LCD : 16×2 Alphanumeric Display + ATC |
|
| Resolution | 0.01 pH | 0.01 pH | ||||
| Accuracy | ± 0.01 ± 1 digit | ± 0.01 ± 1 digit | ||||
| mV | Range | 0 ± 2000 mV | 0 ± 2000 mV | |||
| Resolution | 1 mV | 1 mV | ||||
| Accuracy | ± 1 mV | ± 1 mV | ||||
| Temp. | Range | Not
Available |
0 to 100ºC | |||
| Resolution | 1ºC | |||||
| Accuracy | ± 1ºC | |||||
| TemperatureComp. | Manual By knob( Temp. Scale ) Settable | ManualDigitally Settable | ATC | ATC | ||
| Auto BufferRecognition & Auto Buffer
Calibration |
2 Points, Automatic(4.00, & 7.00) | 3 Points, Automatic(4.00,
7.00 & 9.20 pH) |
3 Points,Automatic
(4.00, 7.00 & 9.20 pH) |
3 Points, Automatic(4.00, 7.00 &
9.20 pH) |
||
| Power Supply : 12V/ 500mA External AdopterComplete Accessories : pH Electrode Combined, Electrode
Stand, Buffer Solution, Dust Cover & Manual. |
||||||
Features
- Reliable & Accurate Results
- Measurements upto 1000 NTU
- 3½ Digit 7-Segment LED Display
- Sewage and Drinking Water Testing
Clarity of water is extremely important in products destined for human consumption. Suspension free water is also considered necessary for industries manufacturing beverage, food products etc. Similarly, minimum limits of turbidity are required to be observed in drinking water & sewage disposals.
Ei’s Digital Turbidity Meter and Nephelometer are ideal instruments for measurement of suspensions. They consist of a light source focused on a test tube containing the sample solution under test. The light, reflected at right angle to the focused light by the suspension in the solution, is detected by the photo electric detector, amplified and displayed on a 3½ digit LED display.
Specifications
| Model | PRYG-335 | PRYG-335A | PRYG-335B |
| Product | Digital Turbidity Meter |
Digital Turbidity Meter |
Digital Nephelometer |
| Range | 0 – 1000 NTU (in 4 Ranges) 0 – 2, 20, 200, 1000 NTU |
0 – 1000 NTU (in 2 Ranges) 0 – 200, 1000 NTU |
0 – 200 NTU (in 2 Ranges) 0 – 20, 200 NTU |
| Resolution | 0.01 NTU | 1 NTU | 0.1 NTU |
| Accuracy | ± 3% FS, ± 1Digit | ± 3% FS, ± 1Digit | ± 2% FS, ± 1Digit |
| Display | 3½ Digit 7-Segment LED | ||
| Light Source | IR LED | ||
| Detector | Photodiode | ||
| Sample System | 60 x 25mm Clear Glass Test Tubes | ||
| Power | 230 V ± 10% AC, 50 Hz | ||
| Dimensions | 245 x 260 x 125 mm (L x B x H) (Approx.) | ||
| Accessories | Test tube Set of 5, Operation Manual, Dust Cover | ||
